CHALLENGE XTREME
CHALLENGE XTREME 40CM SELF PROPELLED PETROL LAWNMOWER WITH SMV ENGINE
MODEL NUMBER: XSZ40
SAN - 0370000029ZA
2012
SAN - 0370000029ZA
2012
Spare Parts
Take a look below for the spare parts we have available for CHALLENGE XTREME 40CM SELF PROPELLED PETROL LAWNMOWER WITH SMV ENGINE
7
M6X35MM BOLT
B127012B
In stock
£0.80
8
M8 NUT
B201003
In stock
£0.80
12
CABLE CLIP
428032
In stock
£3.00
13
ROPE GUIDE
916223
In stock
£3.50
15
ST4.7X16MM SCREW
B620003
In stock
£0.80
21
SPLIT RING
B282008
In stock
£2.00
25
GRASS BAG FRAME
916221
In stock
£18.00
28
M8 HEX NUT
B217005
In stock
£0.75
29
8MM WASHER
B504008
In stock
£0.80
30
WHEEL BUSH
1200007000
In stock
£3.00
34
INTERNAL WHEEL DUST COVER
932008
In stock
£3.50
35
SHAFT CIRCLIP
B278010
In stock
£2.00
36
LEFT DRIVE GEAR
932401
13 in stock
£5.50
37
BALL BEARING
B700482
In stock
£2.00
39
STRAIGHT PIN 5X21.5MM
932215
In stock
£1.00
41
GEAR BOX
932902
In stock
£33.00
4
DRIVE BELT
932903
In stock
£12.50
49
PARALLEL KEY
916222
In stock
£7.50
52
HEAVY CONE WASHER
916203
In stock
£7.00
53
BLADE BOLT - 3/8"-24
932217
In stock
£5.00
50
LONG SHAFT BLADE ADAPTER
932101
In stock
£17.50
55
WHEEL
1050090001
In stock
£10.00
1.1
SPARK PLUG TOOL FOUR STROKE
933220
In stock
£7.50
-
START ASSEMBLY SV150
923915
16 in stock
£17.50
51
BLADE 40CM
916202
In stock
£14.00
-
WHEEL 200MM
932006
In stock
£7.50
-
BRAKE CABLE SET
916903
In stock
£12.50
14
BELT COVER
932004
In stock
£14.00
19
ENGINE BOLT - M8X40MM
B131022
In stock
£5.50
20
CONNECTION ROD COVER
932003
In stock
£10.00
32
INTERNAL GEAR WHEEL
932007
In stock
£10.00
38
PLASTIC BUSH
932009
In stock
£3.50
40
SPRING GEAR BOX
932502
In stock
£5.50
43
REAR SHAFT ASSEMBLY
932212
In stock
£12.00
44
REAR PRESSED PLATE
932213
In stock
£12.00
45
PAN HEAD TAPPING SCREW - ST4.8X25MM
B400036F
In stock
£5.50
46
SPRING PIN
932504
In stock
£5.00
47
CONNECTION ROD SET
932216
In stock
£10.00
48
RETURN SPRING
932503
In stock
£10.00
56
FRONT PRESSED PLATE
932211
In stock
£5.50
57
FRONT SHAFT ASSY
932207
In stock
£18.00
58
BOLT- M5X14MM
B127003
In stock
£2.00
59
WHEEL HEIGHT SELECTOR
932210
In stock
£12.00
60
M5 NUT
B217003
In stock
£0.80
64
HEXAGON HEAD BOLT
B125004
In stock
£5.50
65
ST4.8X16MM SCREW
B400062F
In stock
£0.80
66
GEAR BOX BUSH
932403
In stock
£4.00
67
RETAINING PLATE
932214
In stock
£6.00
68
RIGHT DRIVE GEAR
932402
13 in stock
£5.50
A1
START ASSEMBLY SV150
923915
16 in stock
£17.50
120
AIR FILTER COVER
923012
In stock
£10.00
14
FUEL TANK
923017
In stock
£25.00
99
IGNITION COIL
923702
In stock
£17.50
93
TENSION SPRING
923509
In stock
£2.00
